| PANEL |
23.8" (IPS) |
| PIXEL PITCH (MM) |
0.2745 (H) × 0.2745 (V) |
| EFFECTIVE VIEWING AREA (MM) |
527.04 (H) × 296.46 (V) |
| BRIGHTNESS (TYPICAL) |
300 cd/m² |
| CONTRAST RATIO |
1100 : 1 (Typical) 80 Million : 1 (DCR) |
| RESPONSE TIME |
1ms (MPRT) |
| VIEWING ANGLE |
178° (H) / 178° (V) (CR > 10) |
| COLOR GAMUT |
NTSC 96% (CIE1976) / sRGB 125% (CIE1931) / DCI-P3 87% (CIE1976) |
| COLOR ACCURACY |
Delta E < 2 |
| OPTIMUM RESOLUTION |
1920 × 1080 @ 165Hz – DisplayPort, 1920 × 1080 @ 144Hz – HDMI, 1920 × 1080 @ 60Hz – VGA |
| DISPLAY COLORS |
16.7 Million |
| SIGNAL INPUT |
VGA × 1 / HDMI 1.4 × 2 / DisplayPort 1.2 × 1 |
| HDCP VERSION |
HDMI: 1.4 / DisplayPort: 1.4 |
| USB HUB |
no |
| POWER SUPPLY |
100 - 240V～1.5A, 50 / 60Hz |
| POWER CONSUMPTION (TYPICAL) |
22W |
| SPEAKERS |
no |
| LINE IN & EARPHONE |
Earphone |
| WALL-MOUNT |
100mm × 100mm |
| ADJUSTABLE STAND |
Height: 130mm, Swivel: -30° ~ 30°, Pivot: 0°~90° ± 2°, Tilt: -5° ~ 23° |
| PRODUCT WITHOUT STAND (MM) |
322.1 (H) × 539.05 (W) × 47.2 (D) |
| PRODUCT WITH STAND (MM) |
374.6~504.6 (H) × 539.1 (W) × 227.4 (D) |
| PRODUCT WITHOUT STAND (KG) |
2.8 |
| PRODUCT WITH STAND (KG) |
4.25 |
| CABINET COLOR |
Black & Red |
| REGULATORY APPROVALS |
BSM / KC / KCC / e-Standby / RCM / MEPS / CE / CB / FCC |
