| PANEL |
23.8" (IPS) |
| PIXEL PITCH (MM) |
0.2745 (H) ร— 0.2745 (V) |
| EFFECTIVE VIEWING AREA (MM) |
527.04 (H) ร— 296.46 (V) |
| BRIGHTNESS (TYPICAL) |
250 cd/m² |
| CONTRAST RATIO |
1000 : 1 (Typical) 20 Million : 1 (DCR) |
| RESPONSE TIME |
4ms (GtG) |
| VIEWING ANGLE |
178° (H) / 178° (V) (CR > 10) |
| COLOR GAMUT |
NTSC 88% (CIE1976) / sRGB 101% (CIE1931) |
| COLOR ACCURACY |
- |
| OPTIMUM RESOLUTION |
1920 x 1080 @ 75Hz -- DisplayPort, HDM |
| DISPLAY COLORS |
16.7 Million |
| SIGNAL INPUT |
HDMI 1.4 x 1 , DisplayPort 1.2 x 1 |
| HDCP VERSION |
HDMI: 1.4, DisplayPort: 1.2 |
| USB HUB |
no |
| POWER SUPPLY |
19VDC, 1.31A |
| POWER CONSUMPTION (TYPICAL) |
15W |
| SPEAKERS |
no |
| LINE IN & EARPHONE |
Earphone |
| WALL-MOUNT |
100mm x100mm |
| ADJUSTABLE STAND |
Height: 130mm, Pivot:90° ~ 90°, Swivel: -30° ~ 30°, Tilt: -5° ~ 23° |
| PRODUCT WITHOUT STAND (MM) |
341.7 (H) × 542.4 (W) × 37.5 (D) |
| PRODUCT WITH STAND (MM) |
366.9 ~496.9 (H) × 542.4(W) × 190 (D) |
| PRODUCT WITHOUT STAND (KG) |
2.49 |
| PRODUCT WITH STAND (KG) |
4.22 |
| CABINET COLOR |
Black |
| REGULATORY APPROVALS |
CE/ FCC |
