| PANEL |
23.8" / IPS |
| PIXEL PITCH (MM) |
0.2745 (H) x 0.2745 (V) |
| EFFECTIVE VIEWING AREA (MM) |
527.04 (H) x 296.46 (V) |
| BRIGHTNESS (TYPICAL) |
250 cd/m2 |
| CONTRAST RATIO |
1000 : 1 (Typical) 20 Million : 1 (DCR) |
| RESPONSE TIME |
4ms (GtG) |
| VIEWING ANGLE |
178° (H) / 178° (V) (CR > 10) |
| COLOR GAMUT |
NTSC 83% (CIE1976) / sRGB 102% (CIE1931) |
| COLOR ACCURACY |
|
| OPTIMUM RESOLUTION |
1920 x 1080 @ 100Hz - HDMI |
| DISPLAY COLORS |
16.7 Million |
| SIGNAL INPUT |
HDMI 1.4 x 2 |
| HDCP VERSION |
|
| USB HUB |
No |
| POWER SUPPLY |
External 19VDC, 1.31A |
| POWER CONSUMPTION (TYPICAL) |
17W |
| SPEAKERS |
No |
| LINE IN & EARPHONE |
Earphone x 1 |
| WALL-MOUNT |
100mm x 100mm |
| ADJUSTABLE STAND |
Tilt: 5° ~ 20° |
| PRODUCT WITHOUT STAND (MM) |
320.9 (H) x 539.5 (W) x 37.5 (D) |
| PRODUCT WITH STAND (MM) |
418.4 (H) x 539.5 (W) x 170.9 (D) |
| PRODUCT WITHOUT STAND (KG) |
2.44 kg |
| PRODUCT WITH STAND (KG) |
2.78 kg |
| CABINET COLOR |
Black |
| REGULATORY APPROVALS |
CE / FCC |
