| Brand |
LONGWELL ราคา 1,290 บาท Inc.Vat |
| Model |
INTEL G41-D3C
|
| CPU Support |
Intel® Celeron
Intel® Celeron Dual-Core
Intel® Core 2 Duo
Intel® Core 2 Extreme
Intel® Core 2 Quad
Intel® Pentium Dual-Core
|
| Socket |
775
|
| Chipset |
G41 Express
|
| Memory Support |
Dual Channel DDR3 Memory Technology
2 x DDR3 DIMM Slots
Support DDR3 1600/1333/1066 MHz Non-ECC, Un-Buffered
Max.capacity up to 8GB Memory
|
| Memory Type |
DDR3
|
| Memory Bus |
1600 / 1333 / 1066 MHz
|
| Memory Slot |
2 Slots
|
| Audio |
Support 6 channels sound input (ex:Realtek ALC662)
Support 16-bit ADC (Analog Digital Converter)
Support multipls stereo input mixer
|
| FSB |
Support FSB 1333/1066/800/533MHz |
| Expansion Slots |
1 x PCI Express 2.0 x16 (x16 mode)
1 x PCI Slot
|
| Storage |
4 x SATA2 Connector
1 x IDE Port
|
| Internal I/O Connectors |
1 x 24 pin EATX power connector
1 x 4 pin ATX 12V power connector
1 x CPU Fan connector
2 x F USB 2.0 connector
1 x Front panel audio connector (AAFP)
1 x Speaker connector
1 x System panel connector
|
| Back Panel Connectors |
1 x PS/2 Mouse Port
1 x PS/2 Keyboard Port
1 x VGA (D-Sup) Port
1 x Serial Port (Com1)
1 x Parallel Port (LPT)
4 x USB 2.0 Port
1 x RJ-45 LAN Port
3 x Audio Jacks : Line in / Speaker / Microphone
|
| LAN |
10/100 Mb/s auto negotiation Half/Full duplex capability Realtek RTL8105E
|
| Form Factor |
Micro ATX Form Factor : 21.2 cm x 17.0 cm
|
| Operating System Support |
Microsoft® Window® XP / Vista / 7 / 8 / 10
|
| Package Dimension |
(W x D x H) : 23.00 x 28.00 x 5.50 cm |
| Gross Weight |
0.60 KG |
| Volume |
3,542.00 cm3 |
